CESAB S210 User Manual

© Cesab 8 – 57 T Code(s): 841, 842, 843
Repair manual: Troubleshooting Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
8.10.2 Test function “10” – Logic card
Function Pos 1 Pos 2 Pos 3 Pos 4
- A * * * Not assigned
- B * * * Not assigned
- C * * * Not assigned
Front fork lift button [A5:S19] D * * * Lit: Button depressed
Front fork lowering button
[A5:S20]
E * * *
Lit: Button depressed
Rear fork lift button [A5:S21] F * * * Lit: Button depressed
Rear fork lowering button
[A5:S22]
G * * *
Lit: Button depressed
Sound signal control [S18] H * * * Lit: Button depressed
Outermost option button, right
side [S116]
* A * *
Lit: Button depressed
Centre option button, right side
[S115]
* B * *
Lit: Button depressed
Innermost option button, right
side [S114]
* C * *
Lit: Button depressed
Outermost option button, left
side [S113]
* D * *
Lit: Button depressed
Centre option button, left side
[S206]
* E * *
Lit: Button depressed
Innermost option button, left
side [S111]
* F * *
Lit: Button depressed
- ‘ G * * Not assigned
- * H * * Not assigned
A
B
C
D
E
F
G
H
