Name: CESAB S210
Brand: CESAB
Rating: 5 (1 reviews)

To Next Page

To Previous Page

T Code(s):

841, 842, 843

Repair manual:

Hydraulics chart

Model(s):

S210, S212, S212S, S212L, S214, S214L, S220D

Publication Number:

7588857-040

Date:

2018-05-01

Applies from serial number:

6384351-

21. Hydraulics chart

Support arms

Duplex Hilo

Triplex Hilo

Simplex/

Duplex tele

panoramic

Q23 Q22

Max 230 Bar
