© Cesab 12 – 4 T Code(s): 841, 842, 843
Repair manual: Brake system/Wheels C3000 Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
12.3 Removing the parking brake
DANGER!
Risk of brake function being lost.
When work is done in the brake system, there is a risk of brake function being
partly or completely lost.
• Truck switched off and the battery disconnected
• Motor compartment open
1. Remove the steering yoke from the truck together with the tiller arm (see
the repair manual). Note the position of the conduit entry so that refitting
is done correctly.
2: Remove the brake and the cable connector Q1.
3. Remove the brake unit from the truck. Note the position of the brake so
that refitting is done correctly.
