© Cesab 23 – 1
T Code(s):
841, 842, 843
Repair manual:
Lubricants specification
Model(s):
S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number:
7588857-040
Date:
2018-05-01
Applies from serial number:
6384351-
23. Lubricants specification
23.1 General tightening torques
Millimetre threads M3 to M24. The following applies in the case of good
conditions, e.g. steel against steel.
Tightening torque ‘T’ (Nm)
Note:
Experience has shown that if the torque wrench is adjusted to the values for untreated
screws, the correct torque value for galvanised screws will also be obtained. Do not
tighten more than the values indicated in the table, otherwise the screws can be
destroyed.
Galvanised,
not oiled screws
Untreated,
oiled screws
Strength class:
Dimension
Strength class:
8.8 10.9 12.9 8.8 10.9 12.9
1.1 1.6 2.0 M3 1.2 1.7 2.1
2.8 3.8 4.7 M4 2.9 4.0 4.9
5.5 7.7 9.3 M5 5.7 8.1 9.7
9.5 13 16 M6 9.8 14 17
23 32 38 M8 24 33 40
45 62 76 M10 47 65 79
78 109 130 M12 81 114 136
123 174 208 M14 128 181 217
189 266 320 M16 197 277 333
370 519 623 M20 385 541 649
638 898 1075 M24 665 935 1120
