CESAB S210 - Parameter 1002 - Non-configurable options

© Cesab 5 – 27 T Code(s): 841, 842, 843
Repair manual: Parameters Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
Parameter 1002 - Non-configurable options
#1002 - Non-configurable options
3 different functions are accessible via parameter 1002. These functions are
either active or inactive. The functions do not require any further adjustment
and are thus referred to as non-configurable options.
Par. Description Min.
Defa
ult
Max.
Incre
ment
Unit
1002 Non-configurable option 0 1 7 1
Value Function
0 No optional function
1 CLICK-2-CREEP
2 TURTLE
3 CLICK-2-CREEP and TURTLE
4 SAFETY REVERSING HORN
5 SAFETY REVERSING HORN and CLICK-2-CREEP
6 SAFETY REVERSING HORN and TURTLE
7
SAFETY REVERSING HORN, CLICK-2-CREEP and
TURTLE
