CESAB S210 User Manual

© Cesab 18 – 4 T Code(s): 841, 842, 843
Repair manual: Accessories Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
18.6 Built-in battery charger
Note:
If retrofitting the built-in battery charger, TruckCom is required to be able to
set all necessary parameters. TruckCom is not needed if replacing an
existing charger. When installing the charger, torque tighten nuts (A) to max.
1.6 Nm.
If the truck is factory-fitted with a battery, the battery charger is adjusted to
suit the battery.
If the truck is delivered from the factory without a battery, the customer/
technician must set the right parameters based on battery type and size
18.6.1 Technical data
Designation SMCO 24/30
Dimensions, mm 240x111x77
Weight, kg 1.7
Ambient temperature, ºC -25 - +40
Mains voltage, V AC 195-264
Rated voltage, V DC 24
Rated current, A 30
Maximum output, W 800
B
A
C
D
D
