© Cesab 9 – 4 T Code(s): 841, 842, 843
Repair manual: Chassis 0000 Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
8. Change the upper stop screws for M8 x 120, washers are not needed.
9. Remove and discard the screws to the upper bracket.
10. Remove the lower screws.
11. Compress the spring assembly using the threaded bar until the lips are
clear.
12. Unload the springs by prying up the bracket using the threaded bar.
Note:
Check that the bushings do not get stuck or become damaged during
reassembly.
