© Cesab 15 – 11 T Code(s): 841, 842, 843
Repair manual: Hydraulic system 6000 Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
4. Turn the adjusting screw clockwise until the truck is able to lift the load
without any problem.
5. Tighten the locking nut (c) clockwise.
6. Refit the washer and protective cover (b)
7. Push a new sealing cap (a) onto the pressure limiting valve
Once the truck manages to lift the rated load, apply an additional 100 kg on
the forks. Verify that the truck cannot lift the load.
If the truck is able to lift 100 kg more than its rated load:
1. Pry off the sealing cap (a) attached to the pressure limiting valve using a
screwdriver.
2. Remove the protective cover (b) (17 mm) by turning it anti-clockwise.
Remove the protective cover and the washer housed inside it.
3. Loosen the locking nut (c) (17 mm) by turning it anti-clockwise.
4. Turn the adjusting screw counter-clockwise until the truck cannot lift the
load.
5. Tighten the locking nut (c) clockwise.
6. Refit the washer and protective cover (b)
7. Push a new sealing cap (a) onto the pressure limiting valve
