© Cesab 24 – 2
T Code(s):
841, 842, 843
Repair manual:
Technical data
Model(s):
S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number:
7588857-040
Date:
2018-05-01
Applies from serial number:
6384351-
Wheels
Drive wheel, mm 230
Wheel pressure (kg/mm²) 0.2 0.22 0.24
Axle pressure without load, kg 350 400 450
Axle pressure at rated load, kg 350 400 450
Wheel bolts tightening torque, Nm 81±19
Support arm wheels, mm 125
Axle pressure without load, kg 235 285 285
Axle pressure at rated load kg 1185 1445 1640
Castor wheel, mm 85
Axle pressure without load, kg 230 250 200
Axle pressure at rated load, kg 280 290 245
Hydraulic system
Power, kW 2.2
Duty factor, % S2,60 min
Min. carbon brush length, mm 8
Min. commutator thickness/
diameter, mm
-
Pressure at rated load, bar
See section “24.4 Overflow pressure for mast”.Overflow pressure, bar
Pump flow, litres/minute
Tank volume, litres 4.5
Hydraulic oil See section “23.2 Lubricants specification”.
Fuses
Drive motor circuit, A 125
Pump motor circuit, A 125
Control circuit, A 7.5
Model S210 S212 S214
