© Cesab 24 – 8
T Code(s):
841, 842, 843
Repair manual:
Technical data
Model(s):
S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number:
7588857-040
Date:
2018-05-01
Applies from serial number:
6384351-
Wheels
Drive wheel, mm 230
Wheel pressure (kg/mm²) 0.32
Axle pressure without load, kg 675
Axle pressure at rated load, kg 635
Wheel bolts tightening torque, Nm 81±19
Support arm wheels, mm 100
Axle pressure without load, kg 340
Axle pressure at rated load kg 1580
Castor wheel, mm -
Axle pressure without load, kg -
Axle pressure at rated load, kg -
Hydraulic system
Power, kW 2.2
Duty factor, % S2,60 min
Min. carbon brush length, mm -
Min. commutator thickness/
diameter, mm
-
Pressure at rated load, bar
See section “24.4 Overflow pressure for mast”.Overflow pressure, bar
Pump flow, litres/minute
Tank volume, litres 4.5
Hydraulic oil See section “23.2 Lubricants specification”.
Fuses
Drive motor circuit, A 125
Pump motor circuit, A 125
Control circuit, A 7.5
Model S212S
