© Cesab 7 – 10 T Code(s): 841, 842, 843
Repair manual: Maintenance Model(s): S210, S212, S212S, S212L, S214, S214L, S220D
Publication Number: 7588857-040 Date: 2018-05-01 Applies from serial number: 6384351-
Truck area Pos. Measure 750h/12m Time
expen
diture
4110 Tiller arm
a Check for proper attachment. X 1:45
minutes
b Inspect the operating console for correct
mounting.
X
c Check the mounting of the handle. X
d Check the force and locking of the gas
spring.
The tiller arm should return to the top
position both from the bottom position
and from the lower position where the
brake is applied.
X
Check that the braking function is
activated in both upper and lower tiller
arm positions.
