CS35 2013.04
3.1.13-91 3.1.13-91Electronic Control System - ME7
Diagnostic Tool
Display Item
Description
Control
Range
Diagnostic Description
Carbon canister
control valve
Enable the carbon canister
control valve
0 ~ 100
CAUTION: The vacuum
degree measured by the fuel
tank vacuum sensor shall be
less than the setting match
threshold (pte_W> DPTEBU);
in the enhanced evaporation
system, the setting match
fuel tank protection algo-
rithm shall not go wrong
(E_TES).
Control the carbon canister control
command, which is between 0 ~ 100,
realizing control over cleaning flow of
carbon canister.
Fuel pump relay Enable the fuel pump relay On / Off
CAUTION: This test can only
be carried out only when
vehicle speed is 0 and speed
sensor is with no fault.
This function could control fuel pump
relay. When the command is "ON", the
fuel pump relay will be energized / de-
energized within 3 ~ 5 s.
Cooling fan relay # 1 Enable low speed EDF relay On / Off
CAUTION: Carry out the test
only when engine coolant
temperature is lower than
100 (212 ºF) with A/C
switch off.
This function could control low speed
EDF relay. When the command is
"ON", the electronic fan will be started
at low speed for 5 s.
Cooling fan relay # 2 Enable high speed EDF relay On / Off
Carry out the test only when
engine coolant temperature
is lower than 100 (212 ºF)
with A/C switch off.
This function could control high speed
electronic fan relay. When the com-
mand is "ON", the electronic fan will be
started at high speed for 5 s.
