3.1.13-141 3.1.13-141Electronic Control System - ME7
DTC P0221, P0222 and P0223
1. DTC Description
2. Possible Sources
Fault Code Description Definition
P0221
Electrical throttle position sensor
signal 2 unreasonable
• ECM provides 5V reference voltage to terminal 3
of TPS sensor wiring harness connector E23
through terminal 32 of wiring harness connector
E01.
• TPS provides sensor signal voltage to terminal 38
of ECM wiring harness connector E01 through ter-
minal 5 of E23.
• ECM positions terminal 2 of TPS sensor wiring
harness connector E23 at low electrical potential
through terminal 78 of wiring harness connector
E01.
P0222
Electrical throttle position sensor
signal 2 circuit voltage too low
P0223
Electrical throttle position sensor
signal 2 circuit voltage too high
Fault
Code
Test Tactics
Setting Conditions (Control
Strategy)
Fault
P0221
Throttle position
sensor 2 and throt-
tle position sensor 1
is inconsistent.
more than the spe
ified value, or throt-
tle position sensor 1
and the expected
value is inconsi
tent, more than the
specified value.
Turn ignition switch to position "ON",
and engine is off or is running.
• Sensor circuit fault
• Sensor fault
• ECM fault
P0222
Signal circuit volt-
age too low, short
circuit to ground
P0223
Signal circuit volt-
age too high, short
circuit to power
supply
