CS35 2013.04
3.1.13-93 3.1.13-93Electronic Control System - ME7
DTC Diagnostic Procedure Index
Fault Code Description Diagnosis Procedures
P000A Slow reaction of intake VVT
Refer to: DTC P000A, P0012,
P0010, P2088, P2089
P0010
Open circuit of the VVT intake control valve
circuit
P0012
The intake VVT is not in the default position
when starting
P2088
Short circuit to ground of the VVT intake con-
trol valve circuit
P2089
Short circuit to power supply of the VVT intake
control valve circuit
P000B Slow reaction of exhaust VVT
Refer to: DTC P000B, P0013,
P0015, P2090, P2091
P0013
Open circuit of the VVT exhaust control valve
circuit
P0015
The exhaust VVT is not in the default location
when starting
P2090
Short circuit to ground of the VVT exhaust
control valve circuit
P2091
Short circuit to power supply of the VVT
exhaust control valve circuit
P0016
Relative installation position of camshaft and
crankshaft unreasonable
Refer to: DTC P0016, P0017
P0017
Relative installation position of camshaft and
crankshaft unreasonable
P0030
Upstream oxygen sensor heating control cir-
cuit fault
Refer to: DTC P0030, P0031, P0032,
P0053
P0031
Upstream oxygen sensor heating control cir-
cuit voltage too low
P0032
Upstream oxygen sensor heating control cir-
cuit voltage too high
P0053
Upstream oxygen sensor heating internal
resistance unreasonable
P0036
Downstream oxygen sensor heating control
circuit fault
Refer to: DTC P0036, P0037, P0038,
P0054
P0037
Downstream oxygen sensor heating control
circuit voltage too low
P0038
Downstream oxygen sensor heating control
circuit voltage too high
P0054
Downstream oxygen sensor heating internal
resistance unreasonable
