CS35 2013.04
3.1.13-109 3.1.13-109Electronic Control System - ME7
7. Inspect the unstable camshaft position sensor signal
A. Turn the ignition switch to position "ON", engine
doesn't run.
B. Clear the DTC with diagnostic tool.
C. Starting the engine.
D. Gently tap and swing crankshaft position sensor.
E. Turn the ignition switch to position "ON", engine
doesn't run.
F. Inspect the sensor wiring harness connector, and
inspect the ECM wiring harness connector for
damaged, bent, corrosion or pulled pins / terminals.
G. Inspect the crankshaft position sensor circuit
relative connector.
Are the DTC P0016 , P0017 still there?
Y
Go to step 8.
N
Repair the fault circuit based on the inspect, replace
as necessary.
Refer to: Crankshaft Position Sensor
(3.1.13 Electrical Control System - ME7,
Removal and Installation).
8. Inspect the crankshaft position sensor signal wheel
A. Turn the ignition switch to position "LOCK".
B. Rotate the flywheel, inspect the crankshaft position
sensor signal wheel for worn and dirty attachments.
Y
Go to step 9.
N
Replace the crankshaft position sensor signals
wheel.
Refer to: Main Bearing, Crankshaft and
Cylinder Body (3.1.2 Mechanical System,
Disassembly and Assembly).
Test Conditions Details/Results/Actions
