Changan CS35 - Difficult Warm Start Diagnosis

3.1.13-32
CS35 2013.04
3.1.13-32Electronic Control System - ME7
Difficult Warm Start Diagnosis
Test Conditions Details/Results/Actions
1. Inspect the trouble code
A. Connect the diagnostic tool
B. Turn the ignition switch to position "ON", diagnose
the engine system.
Is there any DTC?
Y
Go to trouble code diagnosis procedure.
Refer to: DTC Diagnostic Procedure Index
(3.1.13 Electrical Control System - ME7,
DTC Diagnosis and Testing).
N
Go to step 2.
2. Inspect the ignition system
A. Turn the ignition switch to position "LOCK".
B. Carry out the ignition spark test.
Refer to: Ignition Spark Testing (3.1.8 Igni-
tion System, General Procedures).
Is the spark plug ignition spark test normal?
Y
Go to step 3.
N
Inspect the ignition system.
Refer to: Spark Plugs Not Flash Over
Diagnosis (3.1.8 Ignition System, Symp-
tom Diagnosis and Testing).
3. Inspect the fuel pressure
A. Turn the ignition switch to position "LOCK".
B. Measure the fuel pressure.
Refer to: Fuel System Pressure Test (3.1.7
Fuel System, General Procedures).
Is the fuel pressure normal?
Y
Go to step 4.
N
Inspect the fuel system.
Refer to: Fuel Pump Not Work Diagnosis
(3.1.7 Fuel System, Symptom Diagnosis
and Testing).
