CS35 2013.04
3.1.13-259 3.1.13-259Electronic Control System - ME7
Knock Sensor
Removal
Installation
1. To install, reverse the removal procedure.
1. Disconnect the battery negative cable.
Refer to: Battery Inspection (3.1.10 Charg-
ing System, General Procedures).
2. Remove the intake manifold reinforcement
plate retaining bolt.
Torque: 23 Nm
3. Replace the knock sensor.
1. Disconnect the knock sensor wiring har-
ness connector.
2. Remove the knock sensor retaining bolt.
Torque: 20 Nm
×4
A3105006
