CS35 2013.04
3.1.13-7 3.1.13-7Electronic Control System - ME7
Fuel Pump Control
The ECU controls the on and off of the fuel pump, in either of the following cases, it connects to the fuel
pump through the fuel pump relay.
• 2 seconds after the ignition switch is turned off.
• When the engine is started (engine start signal is outputted to ECM).
• When camshaft position sensor signal is input in ECM.
Engine
Idle speed
(r/min)
A/C OFF A/C ON
Electric load is off Electric load is on Electric load is off Electric load is on
700 750 800 850
