Changan CS35 User Manual

3.1.13-256
CS35 2013.04
3.1.13-256Electronic Control System - ME7
Fuel Injector
Removal
Installation
1. To install, reverse the removal procedure.
1. Release the fuel pressure.
Refer to: Fuel System Pressure Test (3.1.7
Fuel System, General Procedures).
2. Disconnect the battery negative cable.
Refer to: Battery Inspection (3.1.10 Charg-
ing System, General Procedures).
3. Disconnect the fuel inlet pipe.
4. Remove the fuel distribution pipe.
1. Disconnect the injector wiring harness con-
nectors in sequence.
2. Remove the fuel distribution pipe assembly
retaining bolt.
Torque: 23 Nm
5. Remove the injector from the fuel pipe.
1. Remove the injector retaining clip.
2. Pull out the injector.
A3113148
1
×4
2
×2
A3113150
A3113152
