Changan CS35 User Manual

3.1.13-106
CS35 2013.04
3.1.13-106Electronic Control System - ME7
DTC P0016, P0017
1. DTC Description
2. Possible Sources
3. Diagnosis Procedures
Fault Code Description Definition
P0016
Relative installation position of
camshaft and crankshaft unrea-
sonable
Engine control module ECM uses the crankshaft position
sensor CKP and camshaft position sensor CMP pulse
signal to monitor the correlation between CKP and the
camshaft position. Crankshaft variable reluctance rotor
has 60 teeth, and two teeth are missing and used as a
reference space. Uniform spacing between each tooth is
6 °, only the reference clearance is exception and it is 12
°. Camshaft signal plate has four teeth, two are narrow,
and the other two are wide. The distance between every
four posterior teeth is 90 degrees.
P0017
Relative installation position of
camshaft and crankshaft unrea-
sonable
Fault
Code
Test Tactics
Setting Conditions (Control
Strategy)
Fault
P0016
Relative installation posi-
tion of camshaft and
crankshaft unreason-
able
The difference between learning
value and standard value is big-
ger than 15 kW.
The difference between learning
value and standard valve is less
than 15 kW.
The self - adaption of crankshaft
and camshaft should be acti-
vated.
Camshaft position sensor sig-
nal unstable
Camshaft position sensor sig-
nals wheel
Crankshaft position sensor sig-
nal unstable
Crankshaft position sensor sig-
nals wheel
Camshaft position sensor fault
• Crankshaft position sensor
fault
P0017
Test Conditions Details/Results/Actions
1. General inspection
A. Inspect the camshaft position sensor wiring harness
connector E18, E19, and the crankshaft position
sensor wiring harness connector E07 for loose and
poor contact.
B. Inspect the camshaft position sensor and the
crankshaft position sensor for proper installation.
Is it normal?
Y
Go to step 2.
N
Repair the fault.
