Changan CS35 User Manual

CS35 2013.04
3.1.13-261 3.1.13-261Electronic Control System - ME7
Oil Control Valve
Removal
Installation
1. To install, reverse the removal procedure.
1. Disconnect the battery negative cable.
Refer to: Battery Inspection (3.1.10 Charg-
ing System, General Procedures).
2. Remove the oil control valve.
1. Disconnect the oil control valve wiring har-
ness connector.
2. Remove the oil control valve retaining
screw.
Torque: 10 Nm
3. Take out the oil control valve assembly.
CAUTION: Push the control valve into the
cylinder cover installing hole until the con-
trol valve installing boss touches the cyl-
inder cover when installing the oil control
valve. Do not push the control valve into
the holes forcibly by installing bolt. Make
sure the clip of the control valve harness
wiring connector faces the middle posi-
tion.
2
1
×2
A3113160
1
2
A3102067
