3.1.13-72
CS35 2013.04
3.1.13-72Electronic Control System - ME7
Diagnostic Trouble Code (DTC) Type
75 0.5 BU/BN
Compressor temperature protection
switch signal
-
76 0.5 OG
Air conditioning warm air electronic load
signal
-
77 0.5 OG/BK Crash oil cut - off signal -
78 0.5 OG/BK
Electronic throttle position sensor
grounding
-
79 0.5 GN/WH
Exhaust camshaft position sensor sig-
nal
-
80 0.5 BK G1002 Grounding wire
81 0.3 LG CAN low -
Fault type Definition
Type0 If the fault diagnosis type is 0, no lamp is on, and the system makes no diagnosis.
Type2
Diagnosis path for misfire related fault generally is defined as 2. For the misfire fault
that will cause damage to catalytic converters, the MIL lamp will immediately flash to
warn the driver. For the misfire that may cause the deterioration of emissions faults, if 3
consecutive driving cycles all fully detect the relative level of the fire, then the MIL lamp
is on. The fault will be deleted after 40 continuous trouble - free warm - up cycles.
Type3
After 3 consecutive driving cycles all detected the failure, the MIL lamp is on. If three
consecutive driving cycles detect that the fault has been repaired, the MIL lamp is off.
The failure will be deleted after 40 continuous trouble - free warm - up cycles.
Type5
If 3 consecutive driving cycles all detected the failure, the failure is confirmed. No lamp
is on. If three consecutive driving cycles detect that the fault has been repaired, the MIL
lamp is off. The failure will be deleted after 40 continuous trouble - free warm - up
cycles.
Type6
Once failure occurs and been confirmed, the failure will be deleted after 40 continuous
trouble - free warm - up cycles. No lamp is on for the fault, and universal scan tool is
unreadable.
Type 7
The external test tools can activate the fuel supply system fault diagnosis and are gen-
erally used only for offline testing or repair station. No lamp is on for the fault, and uni-
versal scan tool is unreadable.
Type 11
It is a special diagnostic path for fuel supply system. If three consecutive driving cycles
detect the fault, the MIL lamp is on. If four consecutive driving cycles detect that the
fault has been repaired, the MIL lamp is off. The fault will be deleted after 40 continuous
trouble - free warm - up cycles.
Terminal
No.
Wire Diameter/Color Terminal Definition Remark
