CS35 2013.04
3.1.13-71 3.1.13-71Electronic Control System - ME7
44 0.85 BK/BU
Non continuous power (main relay con-
trol)
-
45 0.85 BK/BU
Non continuous power (main relay con-
trol)
-
46 0.5 GN Canister solenoid valve control signal -
47 0.5 PK/WH Fuel Injector 4 -
48 0.5 BK/YE OCV intake control signal -
49 - - -
50 0.5 YE Low speed fan relay control signal -
51 0.5 BK G1001 Grounding wire
52 - - -
53 0.5 BK G1001 Grounding wire
54 0.5 GN/BK Electronic throttle position 1 -
55 0.85 BK/GN Post - catalytic oxygen sensor signal -
56 - - -
57 - - -
58 0.5 BN/BU Brake lamp switch signal -
59 - - -
60 0.5 BU/GN Tri - state pressure switch signal -
61 0.5 BK G1002 Grounding wire
62 0.3 LG/BK CAN high -
63 0.85 BK/BU
Non continuous power (main relay con-
trol)
-
64 0.5 PK/YE Electrical throttle control -
65 0.5 PK/YE Electrical throttle control -
66 0.5 RD/OG Electrical throttle control -
67 0.5 RD/OG Electrical throttle control -
68 0.5 VT/BU High speed fan relay control signal -
69 0.5 YE/BN Compressor relay control signal -
70 0.5 PK/BN Fuel pump relay control signal -
71 0.5 VT/YE Diagnosis K line -
72 0.5 OG/RD Intake camshaft position sensor signal -
73 0.5 BN/BK Anti - theft device -
74 0.5 BU/WH Clutch top position switch signal input MT
74 - - AT
Terminal
No.
Wire Diameter/Color Terminal Definition Remark
