Changan CS35 User Manual

3.1.13-70
CS35 2013.04
3.1.13-70Electronic Control System - ME7
13 0.5 WH/RD Ignition switch (IG1) -
14 0.5 BK/WH Main relay control signal -
15 0.5 GY/BU Crankshaft position sensor A -
16 0.5 BN Accelerator pedal position sensor 1 -
17 0.5 BU/RD Sensor grounding 1 -
18 0.85 YE/GN Pre - catalytic oxygen sensor signal -
19 0.5 GY/RD Knock sensor A -
20 0.5 GY/GN Knock sensor B -
21 0.5 BN/YE Brake lamp signal -
22 - - -
23 - - -
24 - - -
25 0.5 BU/BK
Post - catalytic oxygen sensor heating
control signal
-
26 0.85 WH/VT
Pre - catalytic oxygen sensor heating
control signal
-
27 0.5 OG/BN Fuel Injector 1 -
28 0.5 BU/YE OCV exhaust vale control signal -
29 - - -
30 - - -
31 - - -
32 0.5 BN/BK 5V power supply 2 -
33 0.5 YE/OG 5V power supply 1 -
34 0.5 GY/VT Crankshaft position sensor B -
35 0.5 RD/YE Sensor grounding 3 -
36 0.5 YE/WH Sensor grounding 2 -
37 0.5 YE/BU Airflow signal -
38 0.5 OG/WH Electronic throttle position 2 -
39 0.5 RD/BK Engine coolant temperature signal -
40 0.5 BN/RD Accelerator pedal position sensor 2 -
41 - - -
42 0.5 GY/YE Air intake temperature signal -
43 - - MT
43 0.5 GY Cruise control switch signal AT
Terminal
No.
Wire Diameter/Color Terminal Definition Remark
