3.1.13-58
CS35 2013.04
3.1.13-58Electronic Control System - ME7
Emergency Occurs During Vehicle Driving Diagnosis
Test Conditions Details/Results/Actions
1. General Procedures
A. Inspect the following items.
• Vacuum pipeline connection
• Air cleaner element
• Air intake system no leakage
• Air intake system no limitation
• The intake manifold and the components
installed on the intake manifold are
correctly sealed.
• Ignition circuit
• Proper quality of fuel (Such as proper
octane value, impurity, winter / summer
mixture)
• Electrical connection
• Stable operation of throttle
Is it normal?
Y
Go to step 2.
N
Repair the fault part.
2. Inspect the trouble code
A. Connect the diagnostic tool.
B. Turn the ignition switch to position "ON", diagnose
the engine system.
Is there any DTC?
Y
Repair and inspect DTC malfunction.
Refer to: DTC Diagnostic Procedure Index
(3.1.13 Electrical Control System - M7,
DTC Diagnosis and Testing).
N
Go to step 3.
