Changan CS35 User Manual

3.1.13-100
CS35 2013.04
3.1.13-100Electronic Control System - ME7
DTC P000A, P0010, P0012, P2088, P2089
DTC Description
2. Possible Sources
3. Diagnosis
Fault Code Description Definition
P000A Slow reaction of intake VVT
• Intake VVT hydraulic control valve circuits consist
of the following:
• Supply voltage: main relay provides reference volt-
age to terminal 2 of intake control valve wiring har-
ness connector E02 through terminal 45 of wiring
harness connector C01 fuse EF23.
• ECM control ground circuit: ECM positions the ter-
minal 1 on intake control valve wiring harness con-
nector E02 to low electric potential through
terminal 48 of ECM wiring harness connector E01.
P0010
Open circuit of the VVT intake
control valve circuit
P0012
The intake VVT is not in the
default location when starting
P2088
Short circuit to ground of the
VVT intake control valve circuit
P2089
Short circuit to power supply of
the VVT intake control valve cir-
cuit
Fault
Code
Test Tactics
Setting Conditions (Control
Strategy)
Fault
P000A
Hardware circuit
inspect
• Short to ground or open circuit
• Short circuit to power supply
• Intake control valve circuit
fault
• Intake control valve fault
• ECM
P0010
P0012
P2088
P2089
Test Conditions Details/Results/Actions
1. General inspection
A. Inspect the intake control valve wiring harness
connector E02 for loose or poor contact.
B. Check if the intake control valve is properly
installed.
Is it normal?
Y
Go to step 2.
N
Repair the fault.
