Changan CS35 User Manual

3.1.13-252
CS35 2013.04
3.1.13-252Electronic Control System - ME7
Electrical Throttle Body
Removal
Installation
1. To install, reverse the removal procedure.
1. Disconnect the battery negative cable.
Refer to: Battery Inspection (3.1.10 Charg-
ing System, General Procedures).
2. Remove the air intake hose and the air filter
connecting clamp.
3. Remove the air intake hose and the electrical
throttle body connecting clamp, and detach
the air filter assembly.
4. Remove the electrical throttle body.
1. Disconnect the electric throttle body wiring
harness connector.
2. Remove the 4 retaining bolts on the electri-
cal throttle body.
3. Take out the electrical throttle body.
Torque: 23 Nm
A3113138
A3104043
2
×4
1
A3113139
