3.1.13-69 3.1.13-69Electronic Control System - ME7
DTC Diagnosis and Testing
Control Module Terminal List
Terminal
No.
Wire Diameter/Color Terminal Definition Remark
1- - -
2 0.75 LG/WH Control signal of the ignition coil 2 MT
2 0.85 RD/BU Control signal of the ignition coil 2 AT
3 2.0 BK G1002 Grounding wire
4- - -
5 0.75 PK/BU Control signal of the ignition coil 1 MT
5 0.85 PK/YE Control signal of the ignition coil 1 AT
6 0.5 WH/YE Fuel injector 2 -
7 0.5 GY Fuel injector 3 -
8- - -
9- - -
10 - - -
11 - - -
12 0.5 RD/WH Continuous power supply -
