CS35 2013.04
3.1.13-107 3.1.13-107Electronic Control System - ME7
2. Inspect the DTC characteristics
A. Use diagnostic tool to clear the DTC.
B. Start the engine and run to operating temperature.
Are the DTC P0016 , P0017 still there?
Y
Go to step 3.
N
Intermittent fault.
Refer to: Intermittent Fault Diagnosis
(3.1.13 Electrical Control System - ME7,
Symptom Diagnosis and Testing).
3. Inspect the ignition timing
A. Inspect the ignition timing.
Refer to: Timing Inspection (3.1.2 Mechan-
ical System, General Procedures).
Is the ignition timing normal?
Y
Go to step 4.
N
Adjust the ignition timing.
4. Inspect the camshaft position sensor
A. Use a diagnostic tool to clear the DTC.
B. Replace a camshaft position sensor that in good
condition, and fasten it with the standard torque.
C. Start the engine and run to operating temperature.
Are the DTC P0016 , P0017 still there?
Y
Go to step 5.
N
Replace the camshaft position sensor.
Refer to: Camshaft Position Sensor (3.1.13
Electrical Control System- ME7, Removal
and Installation).
Test Conditions Details/Results/Actions
