3.1.13-108
CS35 2013.04
3.1.13-108Electronic Control System - ME7
5. Inspect the sensor signal wheel
A. Inspect the camshaft position sensor signal wheel
for worn attachments, or damage.
Is the sensor signal wheel normal?
Y
Go to step 6.
N
Repair the fault part.
6. Inspect the crankshaft position sensor
A. Use a diagnostic tool to clear the DTC.
B. Replace a crankshaft position sensor in good
condition and tighten it to specified torque.
Refer to: Crankshaft Position Sensor
(3.1.13 Electrical Control System - ME7,
Removal and Installation).
C. Start the engine and run to operating temperature.
Are the DTC P0016 , P0017 still there?
Y
Go to step 7.
N
Replace the crankshaft position sensor.
Refer to: Crankshaft Position Sensor
(3.1.13 Electrical Control System - ME7,
Removal and Installation).
Test Conditions Details/Results/Actions
