3.1.13-3 3.1.13-3Electronic Control System - ME7
Item Description Item Description
1 Carbon canister 12 Water temperature sensor
2 Electronic throttle body 13 Knock sensor
3 Carbon canister control valve 14 Crankshaft position sensor
4
Air intake pressure temperature
sensor
15 Fuel pressure regulator
5 Fuel distribution pipe 16 Electronic fuel pump
6 Ignition coil and spark plug 17 Accelerator pedal
7 Camshaft position sensor 18 Anti - burglary
8 Oil control valve 19 Diagnostic interface
9 Pre - catalytic oxygen sensor 20 Fault indicator
10 Three-way catalytic converter 21 CAN
11 Post - catalytic oxygen sensor 22 Electronic control unit (ECU)
