CS35 2013.04
3.1.13-55 3.1.13-55Electronic Control System - ME7
6. Inspect the spark plug
A. Remove the spark plug.
B. Inspect the spark plug in each cylinder and whether
the model and clearance meet the standard.
Refer to: Spark Plug Test (3.1.8 Ignition
System, General Procedures).
Is the spark plug in each cylinder normal?
Y
Go to step 7.
N
Replace the spark plug.
7. Inspect the fuel injector
A. Remove the fuel injector.
B. Inspect the fuel injector for leakage, block or the
phenomenon of flow out of tolerance.
Is the fuel injector normal?
Y
Go to step 8.
N
Replace the fuel injector.
Test Conditions Details/Results/Actions
