159
Appendix II Laser (SE955)
2 Mode 4 or 5, ECI protocol implemented.
3 Mode 2 or 3, ECI protocol implemented in secondary
message.
0 Model 1
1 Model 2, ECI protocol not implemented.
2 Model 2, ECI protocol implemented.
3
Model 2, ECI protocol not implemented, FNC1 implied in first
position.
4
Model 2, ECI protocol implemented, FNC1 implied in first
position.
5
Model 2, ECI protocol not implemented, FNC1 implied in
second position.
QR Code
6
Model 2, ECI protocol implemented, FNC1 implied in second
position
Note: (1) For JPEG files, these BPP settings are ignored for it always uses 8 bits per pixel!
(2) When the image capture feature is enabled, press the [SCAN] button and it will
capture an image instead of reading a barcode.
