11
Quick Start
USING CRADLE
Charging via the Cradle
1. Seat the mobile computer in the cradle.
2. Connect the portable adaptor to the power receptacle on the cradle.
3. Connect the other end of the power adaptor to a suitable power outlet.
4. Connect the USB cable if data transmission is required. Refer to
Using ActiveSync.
Note: Make sure that you have Microsoft ActiveSync installed on your computer before
you connect the cable from the cradle to your computer.
CP30 Indicator
Status Description
Red, solid Charging the mobile computer
Green, solid Charging done
Charging
Red, flashing Battery is abnormal
Cradle Indicator Status Description
Red, solid Charging the spare battery
Green, solid Charging done
Charging
Red, flashing Error occurs
