Press key for 3 seconds to edit the value. The icon appears at the top of the screen.
The key jumps between the possible options.
To validate the data, press for 3 seconds and the icon will disappear from the display.
Configuration values
Table 36:Configuration values: Selecting the screens that will be displayed.
Selecting the screens that will be displayed
Possible values
Yes, the display screens are those that were stored in previous programming
settings of the device. (In the case of new devices, these will be the same as those
of the analyzer profile)
No, the display screens are selected.
Press key to access the next programming step.
6.14.2.- SELECTING THE SCREENS
Note: The following screen is displayed if you have selected the USEr profile. And No has been selected
in, “6.14.1. SELECTING THE SCREENS THAT WILL BE DISPLAYED”.
This screen displays the first screen of the analyzer profile, Phase-phase Voltage and the user profile
viewing option can be selected.
Press key for 3 seconds to edit the value. The icon appears at the top of the screen.
The key jumps between the possible options.
To validate the data, press for 3 seconds and the icon will disappear from the display.
67
Instruction Manual
CVM-C11
