6.37.- BACnet PROTOCOL: BAUD RATE
Note: Not available for model CVM-C11-ITF-IN-ETH-ICT2.
Note: Screen visible if the BACnet protocol has been programmed, “6.31.- RS-485 COMMUNICATIONS:
PROTOCOL”.
The baud rate of BACnet communications is programmed on this screen.
Press key for 3 seconds to edit the value. The icon appears at the top of the screen.
The key jumps between the possible options.
To validate the data, press for 3 seconds and the icon will disappear from the display.
Configuration values
Table 66:Configuration values: BACnet, baud rate.
BACnet: Baud rate
Possible values
9600 bauds
19200 bauds
38400 bauds
Press key to access the next programming step.
6.38.- BACnet PROTOCOL: DEVICE ID
Note: Not available for model CVM-C11-ITF-IN-ETH-ICT2.
Note: Screen visible if the BACnet protocol has been programmed, “6.31.- RS-485 COMMUNICATIONS:
PROTOCOL”.
The device ID is programmed on this screen.
Press key for 3 seconds to edit the value. The icon appears at the top of the screen.
90
CVM-C11
Instruction Manual
