Circutor CVM-E3-MINI - Page 95

Table 69 (Continuation): Modbus memory Map 2: Voltage Harmonics
Map 2
Parameter Voltage L1 Voltage L2 Voltage L3 Units
25th Order harmonic 1A41 1A61 1A81 % x 10
26th Order harmonic 1A42 1A62 1A82 % x 10
27th Order harmonic 1A43 1A63 1A83 % x 10
28th Order harmonic 1A44 1A64 1A84 % x 10
29th Order harmonic 1A45 1A65 1A85 % x 10
30th Order harmonic 1A46 1A66 1A86 % x 10
31st Order harmonic 1A47 1A67 1A87 % x 10
Table 70: Modbus memory Map 1: Current Harmonics
Map 1
Parameter Current L1 Current L2 Current L3 Units
Fundamental Harm. 1F4-1F5 212-213 230-231 mA x 10
2nd Order harmonic 1F6-1F7 214-215 232-233 % x 10
3rd Order harmonic 1F8-1F9 216-217 234-235 % x 10
4th Order harmonic 1FA-1FB 218-219 236-237 % x 10
5th Order harmonic 1FC-1FD 21A-21B 238-239 % x 10
6th Order harmonic 1FE-1FF 21C-21D 23A-23B % x 10
7th Order harmonic 200-201 21E-21F 23C-23D % x 10
8th Order harmonic 202-203 220-221 23E-23F % x 10
9th Order harmonic 204-205 222-223 240-241 % x 10
10th Order harmonic 206-207 224-225 242-243 % x 10
11th Order harmonic 208-209 226-227 244-245 % x 10
12th Order harmonic 20A-20B 228-229 246-247 % x 10
13th Order harmonic 20C-20D 22A-22B 248-249 % x 10
14th Order harmonic 20E-20F 22C-22D 24A-24B % x 10
15th Order harmonic 210-211 22E-22F 24C-24D % x 10
16th Order harmonic 24E-24F 26E-26F 28E-28F % x 10
17th Order harmonic 250-251 270-271 290-291 % x 10
18th Order harmonic 252-253 272-273 292-293 % x 10
19th Order harmonic 254-255 274-275 294-295 % x 10
20th Order harmonic 256-257 276-277 296-297 % x 10
21st Order harmonic 258-259 278-279 298-299 % x 10
22nd Order harmonic 25A-25B 27A-27B 29A-29B % x 10
23rd Order harmonic 25C-25D 27C-27D 29C-29D % x 10
24th Order harmonic 25E-25F 27E-27F 29E-29F % x 10
25th Order harmonic 260-261 280-281 2A0-2A1 % x 10
26th Order harmonic 262-263 282-283 2A2-2A3 % x 10
27th Order harmonic 264-265 284-285 2A4-2A5 % x 10
28th Order harmonic 266-267 286-287 2A6-2A7 % x 10
29th Order harmonic 268-269 288-289 2A8-2A9 % x 10
30th Order harmonic 26A-26B 28A-28B 2AA-2AB % x 10
31st Order harmonic 26C-26D 28C-28D 2AC-2AD % x 10
95
Instruction Manual
CVM-E3-MINI
