Table 72 (Continuation): Modbus memory map: Deleting parameters.
Parameters Address Valid data margin
Deleting three-phase energies 834 FF00
Deleting energies per phase (L1, L2, L3) 873 FF00
Deleting energies per phase (L1) 870 FF00
Deleting energies per phase (L2) 871 FF00
Deleting energies per phase (L3) 872 FF00
Deleting all of the previous parameters 898 FF00
Deleting the digital input pulse counter 884 FF00
7.3.5. POWER STATUS
The function 0x04 is implemented for this variable.
This variable indicates the quadrant in which the device is operating.
Table 73: Modbus memory map: Power status
Power status
Variable Address Default value
Power status 7D1 -
The variable format is shown in Table 74:
Table 74: Variable format: Power status.
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 0 0 0 1: Capacitive 1: Inductive 1: Generated 1: Consumed
7.3.6. DETECTION OF INCORRECT DIRECTION OF ROTATION
The function 0x04 is implemented for this variable.
This variable indicates whether an incorrect direction of rotation has been detected in the voltages.
Table 75: Modbus memory map: Detection of incorrect direction of rotation.
Detection of incorrect direction of rotation
Variable Address Value
Detection of incorrect direction of rotation 7D5
0: No fault has been detected
1: Fault detected
7.3.7. DEVICE SERIAL NUMBER
The function 0x04 is implemented for this variable.
Table 76: Modbus memory map: Device serial number
Device serial number
Variable Address
Serial number 5AA - 5AB - 5AC - 5AD - 5AE - 5AF - 5B0
