Days Display Not Active
Display On Time
Display On Duration
Display Idle Timeout
Step 3
Check the Override Common Settings check box for any changed fields.
Step 4
Click Save.
Step 5
Click Apply Config.
Set up EnergyWise
To reduce power consumption, you can configure the phone to sleep (power down) and wake (power up) if
your system includes an EnergyWise controller.
The Cisco IP Phone 7811 does not support Power Save Plus.Note
You configure settings in Cisco Unified Communications Manager Administration to enable EnergyWise and
configure sleep and wake times. These parameters are closely tied to the phone display configuration parameters.
When EnergyWise is enabled and a sleep time is set, the phone sends a request to the switch to wake it up at
the configured time. The switch returns either an acceptance or a rejection of the request. If the switch rejects
the request or if the switch does not reply, the phone does not power down. If the switch accepts the request,
the idle phone goes to sleep, thus reducing the power consumption to a predetermined level. A phone that is
not idle sets an idle timer and goes to sleep after the idle timer expires.
Procedure
Step 1
From the Cisco Unified Communications Manager Administration, select
Device > Phone and select an individual phone
System > Enterprise Phone Configuration and select a group of users
Device > Device Settings > Common Phone Profile and select the phones.
Step 2
Navigate to the Product Specific Configuration area and set the following fields.
Enable Power Save Plus
Phone On Time
Phone Off Time
Phone Off Idle Timeout
Enable Audible Alert
EnergyWise Domain
Cisco IP Phone 7800 Series Administration Guide for Cisco Unified Communications Manager
145
Phone Feature Configuration
