Set Up Handset for 7811
The Cisco IP Phone 7811 ships with a narrowband or wideband handset. The administrator must configure
the type of the handset for the phone to work.
Procedure
Step 1
In Cisco Unified Communications Manager Administration, choose Device > Phone.
Step 2
Locate the phone that you need to set up.
Step 3
In the Phone Configuration window set the Wideband Handset field:
a) For narrowband handset, set the field to Disabled or Use Phone Default.
b) For wideband handset, set the field to Enabled.
Step 4
Select Save.
Set Up Idle Display
You can specify an idle display (text only; text file size should not exceed 1M bytes) that appears on the phone
screen. The idle display is an XML service that the phone invokes when the phone is idle (not in use) for a
designated period and no feature menu is open.
For detailed instructions about creating and displaying the idle display, see Creating Idle URL Graphics on
Cisco IP Phone at this URL:
http://www.cisco.com/en/US/products/sw/voicesw/ps556/products_tech_note09186a00801c0764.shtml
In addition, see the documentation for your particular Cisco Unified Communications Manager release for
the following information:
Specifying the URL of the idle display XML service:
For a single phone: Idle field in the Phone Configuration window in Cisco Unified Communications
Manager Administration.
For multiple phones simultaneously: URL Idle field in the Enterprise Parameters Configuration
window, or the Idle field in the Bulk Administration Tool (BAT)
Specifying the length of time that the phone is not used before the idle display XML service is invoked:
For a single phone: Idle Timer field in the Phone configuration window in Cisco Unified
Communications Manager Administration.
For multiple phones simultaneously: URL Idle Time field in the Enterprise Parameters Configuration
window, or the Idle Timer field in the Bulk Administration Tool (BAT)
Cisco IP Phone 7800 Series Administration Guide for Cisco Unified Communications Manager
108
