Cisco 7800 Series

The following figure shows the Cisco IP Phone 7841.
Figure 1: Cisco IP Phone 7800 Series Buttons and Features
Indicates whether you have an incoming call (flashing red)
or a new voice message (steady red).
Handset and Handset light strip1
Access your phone lines, features, and call sessions.
For more information, see Softkey, Line, and Feature
Buttons, on page 24.
The Cisco IP Phone 7811 does not have programmable
feature buttons or line buttons.
Programmable feature buttons and line
buttons
2
Access functions and services.
For more information, see Softkey, Line, and Feature
Buttons, on page 24.
Softkey buttons3
Navigation ring and Select button. Scroll through
menus, highlight items, and select the highlighted item.
Navigation cluster4
Cisco IP Phone 7800 Series Administration Guide for Cisco Unified Communications Manager
23
Buttons and Hardware
