Cisco 8832 Administration Guide

Possible Explanation and ActionDescriptionMessage
Obtain a new copy of the phone firmware
and place it in the TFTPPath directory. You
should only copy files into this directory
when the TFTP server software is shut
down; otherwise, the files may be
corrupted.
Downloaded software file is corrupted.ROM Checksum Error
If the phone has a static IP address, verify
that you did not assigned a duplicate IP
address.
If you are using DHCP, check the DHCP
server configuration.
Another device is using the IP address that
is assigned to the phone.
Duplicate IP
None. This message is informational only.Erasing CTL or ITL file.Erasing CTL and ITL files
From Cisco Unified Operating System
Administration, check that the following
files are located within subdirectories in the
TFTP File Management:
• Located in subdirectory with same
name as network locale:
• tones.xml
• Located in subdirectory with same
name as user locale:
• glyphs.xml
• dictionary.xml
• kate.xml
One or more localization files could not be
found in the TFTP Path directory or were
not valid. The locale was not changed.
Error Updating Locale
Cisco IP Conference Phone 8832 Administration Guide for Cisco Unified Communications Manager
125
Cisco IP Conference Phone Troubleshooting
Status Messages Fields

Cisco 8832 Specifications

General

Control type	Buttons
Display type	LCD
Product type	IP conference phone
Voice codecs	G.711a, G.711u, G.722, G.729A, G.729ab, OPUS, iLBC
Certification	CE Markings per directives 2014/30/EU and 2014/53/EU and 2014/35/EU \u2028 \u2028 UL 60950 Second Edition \u2028 CAN/CSA-C22.2 No. 60950 Second Edition \u2028 EN 60950 Second Edition (including A11 and A12) IEC 60950 Second Edition (including A11 and A12) EN 60950-1 IEC 60950-1 AS/NZS 60950.1 47CFR Part 15 (CFR 47) Class B AS/NZS CISPR32 Class B \u2028 CISPR32 \u2028Class B EN55032 \u2028 Class B EN 300 386 ICES003 Class B \u2028 VCCI Class B \u2028 EN61000-3-2 \u2028 EN61000-3-3 \u2028 EN61000-4-2 IEC61000-4-2 EN61000-4-3 IEC61000-4-3 EN61000-4-6 IEC61000-4-6 KN22 Class B \u2028 EN55024 \u2028 CISPR24 \u2028 KN24 Armadillo Light AS/ACIF S004 NZPTC220
Product color	Charcoal
Frequency range	100 - 20000 Hz
Built-in display	Yes
Display diagonal	3.9 \
Languages support	ARA, BUL, CAT, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HEB, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Display resolution	480 x 128 pixels
Security algorithms	EAP-FAST, EAP-TLS, SHA-256, SSH
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPv4, IPv6, SIP, SDP, UDP, DHCP, GARP, TFTP, HTTPS, RTP, RTCP, Cisco Discovery Protocol, LLDP
Cables included	USB
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %
USB connector type	USB Type-C
RJ-45 ports quantity	1

Weight and Dimensions

Width	278 mm
Height	61 mm
Weight	1850 g
