Cisco 8832 Administration Guide

To changeDescriptionOption
Scroll to IPv4 setup and press
Select.
In the IPv4 Setup configuration
submenu, you can do the following:
• Enable or disable the phone to
use the IP address that the
DHCP server assigns.
• Manually set the IP Address,
Subnet Mask, Default Routers,
DNS Server, and Alternate
TFTP servers.
For more information about the
IPv4 address fields, see the “IPv4
Setup Submenu” table.
IPv4 setup
Scroll to IPv6 setup and press
Select.
In the IPv6 setup configuration
submenu, you can do the following:
• Enable or disable the phone to
use the IPv6 address that is
either assigned by DHCPv6
server or acquired by SLAAC
through an IPv6-enabled
router.
• Manually set the IPv6
Address, Prefix Length,
Default Routers, DNS Server,
and Alternate TFTP servers.
For more information about the
IPv6 address fields, see the “IPv6
Setup Submenu” table.
IPv6 setup
Display only. Cannot configure.Unique Media Access Control
(MAC) address of the phone.
MAC address
See Set Domain Name Field, on
page 42.
Name of the Domain Name System
(DNS) domain in which the phone
resides.
Domain name
Step 4 Press Save to make changes or press Revert to discard the connection.
Set the Number of WLAN Authentication Attempts
An authentication request is a confirmation of the user's sign-in credentials. It occurs whenever a phone that
has already joined a Wi-Fi network tries to reconnect to the Wi-Fi server. Examples include when a Wi-Fi
session times out or a Wi-Fi connection is lost and then reacquired.
Cisco IP Conference Phone 8832 Administration Guide for Cisco Unified Communications Manager
45
Cisco IP Conference Phone Installation
Set the Number of WLAN Authentication Attempts

Cisco 8832 Specifications

General

Control type	Buttons
Display type	LCD
Product type	IP conference phone
Voice codecs	G.711a, G.711u, G.722, G.729A, G.729ab, OPUS, iLBC
Certification	CE Markings per directives 2014/30/EU and 2014/53/EU and 2014/35/EU \u2028 \u2028 UL 60950 Second Edition \u2028 CAN/CSA-C22.2 No. 60950 Second Edition \u2028 EN 60950 Second Edition (including A11 and A12) IEC 60950 Second Edition (including A11 and A12) EN 60950-1 IEC 60950-1 AS/NZS 60950.1 47CFR Part 15 (CFR 47) Class B AS/NZS CISPR32 Class B \u2028 CISPR32 \u2028Class B EN55032 \u2028 Class B EN 300 386 ICES003 Class B \u2028 VCCI Class B \u2028 EN61000-3-2 \u2028 EN61000-3-3 \u2028 EN61000-4-2 IEC61000-4-2 EN61000-4-3 IEC61000-4-3 EN61000-4-6 IEC61000-4-6 KN22 Class B \u2028 EN55024 \u2028 CISPR24 \u2028 KN24 Armadillo Light AS/ACIF S004 NZPTC220
Product color	Charcoal
Frequency range	100 - 20000 Hz
Built-in display	Yes
Display diagonal	3.9 \
Languages support	ARA, BUL, CAT, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HEB, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Display resolution	480 x 128 pixels
Security algorithms	EAP-FAST, EAP-TLS, SHA-256, SSH
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPv4, IPv6, SIP, SDP, UDP, DHCP, GARP, TFTP, HTTPS, RTP, RTCP, Cisco Discovery Protocol, LLDP
Cables included	USB
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %
USB connector type	USB Type-C
RJ-45 ports quantity	1

Weight and Dimensions

Width	278 mm
Height	61 mm
Weight	1850 g
