Cisco 8832 Administration Guide

CHAPTER 12
Phone Troubleshooting
• General Troubleshooting Information, on page 157
• Startup Problems, on page 159
• Phone Reset Problems, on page 163
• Phone Cannot Connect to LAN, on page 165
• Cisco IP Phone Security Problems, on page 165
• Audio Problems, on page 167
• General Telephone Call Problems, on page 168
• Troubleshooting Procedures, on page 169
• Control Debug Information from Cisco Unified Communications Manager, on page 172
• Additional Troubleshooting Information, on page 173
General Troubleshooting Information
The following table provides general troubleshooting information for the Cisco IP Phone.
Table 26: Cisco IP Phone Troubleshooting
ExplanationSummary
A prolonged Layer 2 broadcast storm (lasting several
minutes) on the voice VLAN may cause IP phones to
reset, lose an active call, or be unable to initiate or
answer a call. Phones may not come up until a
broadcast storm ends.
Prolonged broadcast storms cause IP phones to reset,
or be unable to make or answer a call
Cisco IP Conference Phone 8832 Administration Guide for Cisco Unified Communications Manager
157

Cisco 8832 Specifications

General

Control type	Buttons
Display type	LCD
Product type	IP conference phone
Voice codecs	G.711a, G.711u, G.722, G.729A, G.729ab, OPUS, iLBC
Certification	CE Markings per directives 2014/30/EU and 2014/53/EU and 2014/35/EU \u2028 \u2028 UL 60950 Second Edition \u2028 CAN/CSA-C22.2 No. 60950 Second Edition \u2028 EN 60950 Second Edition (including A11 and A12) IEC 60950 Second Edition (including A11 and A12) EN 60950-1 IEC 60950-1 AS/NZS 60950.1 47CFR Part 15 (CFR 47) Class B AS/NZS CISPR32 Class B \u2028 CISPR32 \u2028Class B EN55032 \u2028 Class B EN 300 386 ICES003 Class B \u2028 VCCI Class B \u2028 EN61000-3-2 \u2028 EN61000-3-3 \u2028 EN61000-4-2 IEC61000-4-2 EN61000-4-3 IEC61000-4-3 EN61000-4-6 IEC61000-4-6 KN22 Class B \u2028 EN55024 \u2028 CISPR24 \u2028 KN24 Armadillo Light AS/ACIF S004 NZPTC220
Product color	Charcoal
Frequency range	100 - 20000 Hz
Built-in display	Yes
Display diagonal	3.9 \
Languages support	ARA, BUL, CAT, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HEB, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Display resolution	480 x 128 pixels
Security algorithms	EAP-FAST, EAP-TLS, SHA-256, SSH
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPv4, IPv6, SIP, SDP, UDP, DHCP, GARP, TFTP, HTTPS, RTP, RTCP, Cisco Discovery Protocol, LLDP
Cables included	USB
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %
USB connector type	USB Type-C
RJ-45 ports quantity	1

Weight and Dimensions

Width	278 mm
Height	61 mm
Weight	1850 g
