Install the Conference Phone in Daisy Chain Mode
The daisy chain kit contains a Smart Adapter, a short LAN cable, two long, thicker USB-C cables, and a
shorter, thinner USB-C cable. In daisy chain mode, the conference phones require external power from an
electrical outlet. You must use the Smart Adapter to connect the phones together. The long USB-C cables go
to the phone and the short one goes to the power adapter. Refer to the following figure when you connect the
power adapter and the LAN port to the Smart Adapter.
Figure 12: Smart Adapter Power Port and LAN Port
You can use only one microphone per unit.
You must use either two wired microphones or two wireless microphones with the phone, but not a mixed
combination.
Note
The USB-C cable for the power adapter is thinner than the USB-C cables that connect to the phone.
Procedure
Step 1 Plug the power adapter into the electrical outlet.
Step 2 Connect the short, thinner USB-C cable from the power adapter to the Smart Adapter.
Figure 13: Smart Adapter USB Port Connected to the Power Outlet
Step 3 Required: Connect the Ethernet cable to the Smart Adapter and the LAN port.
Cisco IP Conference Phone 8832 Administration Guide for Cisco Unified Communications Manager
34
Cisco IP Conference Phone Installation
Install the Conference Phone in Daisy Chain Mode

Cisco 8832 Specifications

General

Control type	Buttons
Display type	LCD
Product type	IP conference phone
Voice codecs	G.711a, G.711u, G.722, G.729A, G.729ab, OPUS, iLBC
Certification	CE Markings per directives 2014/30/EU and 2014/53/EU and 2014/35/EU \u2028 \u2028 UL 60950 Second Edition \u2028 CAN/CSA-C22.2 No. 60950 Second Edition \u2028 EN 60950 Second Edition (including A11 and A12) IEC 60950 Second Edition (including A11 and A12) EN 60950-1 IEC 60950-1 AS/NZS 60950.1 47CFR Part 15 (CFR 47) Class B AS/NZS CISPR32 Class B \u2028 CISPR32 \u2028Class B EN55032 \u2028 Class B EN 300 386 ICES003 Class B \u2028 VCCI Class B \u2028 EN61000-3-2 \u2028 EN61000-3-3 \u2028 EN61000-4-2 IEC61000-4-2 EN61000-4-3 IEC61000-4-3 EN61000-4-6 IEC61000-4-6 KN22 Class B \u2028 EN55024 \u2028 CISPR24 \u2028 KN24 Armadillo Light AS/ACIF S004 NZPTC220
Product color	Charcoal
Frequency range	100 - 20000 Hz
Built-in display	Yes
Display diagonal	3.9 \
Languages support	ARA, BUL, CAT, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HEB, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Display resolution	480 x 128 pixels
Security algorithms	EAP-FAST, EAP-TLS, SHA-256, SSH
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPv4, IPv6, SIP, SDP, UDP, DHCP, GARP, TFTP, HTTPS, RTP, RTCP, Cisco Discovery Protocol, LLDP
Cables included	USB
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %
USB connector type	USB Type-C
RJ-45 ports quantity	1

Weight and Dimensions

Width	278 mm
Height	61 mm
Weight	1850 g
