Cisco 8832 Administration Guide

http://<IP_address>
Device Information Web Page
The Device Information area on a phone web page displays device settings and related information for the
phone. The following table describes these items.
To display the Device Information area, access the web page for the phone, and then click the Device
Information hyperlink.
Table 20: Device Information Web Page Fields
DescriptionField
The service mode for the phone.Service mode
The domain for the service.Service domain
The current state of the service.Service state
Media Access Control (MAC) address of the phone.MAC Address
Unique, fixed name that is automatically assigned to the phone based on the MAC
address.
Host Name
Directory number that is assigned to the phone.Phone DN
Identifies the application load version.App Load ID
Indicates the boot load version.Boot Load ID
Identifier of the firmware that is running on the phone.Version
Revision value of the phone hardware.Hardware Revision
Unique serial number of the phone.Serial Number
Model number of the phone.Model Number
Indicates whether is a voice message is waiting on the primary line for this phone.Message waiting
Displays the following Cisco Unique Device Identifier (UDI) information about
the phone:
• Hardware type
• Phone model name
• Product identifier
• Version
• Serial number
UDI
Cisco IP Conference Phone 8832 Administration Guide for Cisco Unified Communications Manager
137
Cisco IP Conference Phone Troubleshooting
Device Information Web Page

Cisco 8832 Specifications

General

Control type	Buttons
Display type	LCD
Product type	IP conference phone
Voice codecs	G.711a, G.711u, G.722, G.729A, G.729ab, OPUS, iLBC
Certification	CE Markings per directives 2014/30/EU and 2014/53/EU and 2014/35/EU \u2028 \u2028 UL 60950 Second Edition \u2028 CAN/CSA-C22.2 No. 60950 Second Edition \u2028 EN 60950 Second Edition (including A11 and A12) IEC 60950 Second Edition (including A11 and A12) EN 60950-1 IEC 60950-1 AS/NZS 60950.1 47CFR Part 15 (CFR 47) Class B AS/NZS CISPR32 Class B \u2028 CISPR32 \u2028Class B EN55032 \u2028 Class B EN 300 386 ICES003 Class B \u2028 VCCI Class B \u2028 EN61000-3-2 \u2028 EN61000-3-3 \u2028 EN61000-4-2 IEC61000-4-2 EN61000-4-3 IEC61000-4-3 EN61000-4-6 IEC61000-4-6 KN22 Class B \u2028 EN55024 \u2028 CISPR24 \u2028 KN24 Armadillo Light AS/ACIF S004 NZPTC220
Product color	Charcoal
Frequency range	100 - 20000 Hz
Built-in display	Yes
Display diagonal	3.9 \
Languages support	ARA, BUL, CAT, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HEB, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Display resolution	480 x 128 pixels
Security algorithms	EAP-FAST, EAP-TLS, SHA-256, SSH
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPv4, IPv6, SIP, SDP, UDP, DHCP, GARP, TFTP, HTTPS, RTP, RTCP, Cisco Discovery Protocol, LLDP
Cables included	USB
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %
USB connector type	USB Type-C
RJ-45 ports quantity	1

Weight and Dimensions

Width	278 mm
Height	61 mm
Weight	1850 g
