Cisco 8832 Administration Guide

DescriptionItem
Neighbor device port to which the phone connects
that LLDP discovered.
LLDP Neighbor Port
Speed and duplex information.Port Information
Console Logs, Core Dumps, Status Messages, and Debug Display Web Pages
Under the Device Logs heading, the Console Logs, Core Dumps, Status Messages, and Debug Display
hyperlinks provide information that helps to monitor and troubleshoot the phone.
• Console Logs—Includes hyperlinks to individual log files. The console log files include debug and error
messages that the phone received.
• Core Dumps—Includes hyperlinks to individual dump files. The core dump files include data from a
phone crash.
• Status Messages—Displays the 10 most recent status messages that the phone has generated since it last
powered up. You can also get this information from the Status Messages screen on the phone.
• Debug Display—Displays debug messages that might be useful to Cisco TAC if you require assistance
with troubleshooting.
Streaming Statistics Web Page
A Cisco IP Phone can stream information to and from up to five devices simultaneously. A phone streams
information when it is on a call or is running a service that sends or receives audio or data.
The Streaming statistics areas on a phone web page provide information about the streams.
To display a Streaming Statistics area, access the web page for the phone, and then click a Stream hyperlink.
The following table describes the items in the Streaming Statistics areas.
Table 24: Streaming Statistics Fields
DescriptionItem
IP address and UDP port of the destination of the
stream.
Remote Address
IP address and UPD port of the phone.Local Address
Internal time stamp indicates when Cisco Unified
Communications Manager requested that the phone
start transmitting packets.
Start Time
Indication of whether streaming is active or not.Stream Status
Unique, fixed name that is automatically assigned to
the phone based on the MAC address.
Host Name
Cisco IP Conference Phone 8832 Administration Guide for Cisco Unified Communications Manager
147
Cisco IP Conference Phone Troubleshooting
Console Logs, Core Dumps, Status Messages, and Debug Display Web Pages

Cisco 8832 Specifications

General

Control type	Buttons
Display type	LCD
Product type	IP conference phone
Voice codecs	G.711a, G.711u, G.722, G.729A, G.729ab, OPUS, iLBC
Certification	CE Markings per directives 2014/30/EU and 2014/53/EU and 2014/35/EU \u2028 \u2028 UL 60950 Second Edition \u2028 CAN/CSA-C22.2 No. 60950 Second Edition \u2028 EN 60950 Second Edition (including A11 and A12) IEC 60950 Second Edition (including A11 and A12) EN 60950-1 IEC 60950-1 AS/NZS 60950.1 47CFR Part 15 (CFR 47) Class B AS/NZS CISPR32 Class B \u2028 CISPR32 \u2028Class B EN55032 \u2028 Class B EN 300 386 ICES003 Class B \u2028 VCCI Class B \u2028 EN61000-3-2 \u2028 EN61000-3-3 \u2028 EN61000-4-2 IEC61000-4-2 EN61000-4-3 IEC61000-4-3 EN61000-4-6 IEC61000-4-6 KN22 Class B \u2028 EN55024 \u2028 CISPR24 \u2028 KN24 Armadillo Light AS/ACIF S004 NZPTC220
Product color	Charcoal
Frequency range	100 - 20000 Hz
Built-in display	Yes
Display diagonal	3.9 \
Languages support	ARA, BUL, CAT, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HEB, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Display resolution	480 x 128 pixels
Security algorithms	EAP-FAST, EAP-TLS, SHA-256, SSH
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPv4, IPv6, SIP, SDP, UDP, DHCP, GARP, TFTP, HTTPS, RTP, RTCP, Cisco Discovery Protocol, LLDP
Cables included	USB
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %
USB connector type	USB Type-C
RJ-45 ports quantity	1

Weight and Dimensions

Width	278 mm
Height	61 mm
Weight	1850 g
