Cisco 8832 Administration Guide

Manually Set the Phone Date and Time
With certificate-based authentication, the phone must display the correct date and time. An authentication
server checks the phone date and time against the certificate expiry date. If the phone and the server dates and
times don't match, the phone stops working.
Use this procedure to manually set the date and time on the phone if the phone is not receiving the correct
information from your network.
Procedure
Step 1 From the phone administration web page, scroll to Date & Time.
Step 2 Perform one of the following options:
• Click Set Phone to Local Date & Time to synch the phone to a local server.
• In the Specify Date & Time fields, select the month, day, year, hour, minute, and second using the menus
and click Set Phone to Specific Date & Time.
SCEP Setup
Simple Certificate Enrollment Protocol (SCEP) is the standard for automatically provisioning and renewing
certificates. It avoids manual installation of certificates on your phones.
Configure the SCEP Product Specific Configuration Parameters
You must configure the following SCEP parameters on your phone web page
• RA IP address
• SHA-1 or SHA-256 fingerprint of the root CA certificate for the SCEP server
The Cisco IOS Registration Authority (RA) serves as a proxy to the SCEP server. The SCEP client on the
phone use the parameters that are downloaded from Cisco Unified Communication Manager. After you
configure the parameters, the phone sends a SCEP getcs request to the RA and the root CA certificate is
validated using the defined fingerprint.
Procedure
Step 1 From the Cisco Unified Communications Manager Administration, select Device > Phone.
Step 2 Locate the phone.
Step 3 Scroll to the Product Specific Configuration Layout area.
Step 4 Check the WLAN SCEP Server check box to activate the SCEP parameter.
Step 5 Check the WLAN Root CA Fingerprint (SHA256 or SHA1) check box to activate the SCEP QED parameter.
Simple Certificate Enrollment Protocol Server Support
If you are using a Simple Certificate Enrollment Protocol (SCEP) server, the server can automatically maintain
your user and server certificates. On the SCEP server, configure the SCEP Registration Agent (RA) to:
Cisco IP Conference Phone 8832 Administration Guide for Cisco Unified Communications Manager
82
Cisco IP Conference Phone Administration
Manually Set the Phone Date and Time

Cisco 8832 Specifications

General

Control type	Buttons
Display type	LCD
Product type	IP conference phone
Voice codecs	G.711a, G.711u, G.722, G.729A, G.729ab, OPUS, iLBC
Certification	CE Markings per directives 2014/30/EU and 2014/53/EU and 2014/35/EU \u2028 \u2028 UL 60950 Second Edition \u2028 CAN/CSA-C22.2 No. 60950 Second Edition \u2028 EN 60950 Second Edition (including A11 and A12) IEC 60950 Second Edition (including A11 and A12) EN 60950-1 IEC 60950-1 AS/NZS 60950.1 47CFR Part 15 (CFR 47) Class B AS/NZS CISPR32 Class B \u2028 CISPR32 \u2028Class B EN55032 \u2028 Class B EN 300 386 ICES003 Class B \u2028 VCCI Class B \u2028 EN61000-3-2 \u2028 EN61000-3-3 \u2028 EN61000-4-2 IEC61000-4-2 EN61000-4-3 IEC61000-4-3 EN61000-4-6 IEC61000-4-6 KN22 Class B \u2028 EN55024 \u2028 CISPR24 \u2028 KN24 Armadillo Light AS/ACIF S004 NZPTC220
Product color	Charcoal
Frequency range	100 - 20000 Hz
Built-in display	Yes
Display diagonal	3.9 \
Languages support	ARA, BUL, CAT, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HEB, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Display resolution	480 x 128 pixels
Security algorithms	EAP-FAST, EAP-TLS, SHA-256, SSH
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPv4, IPv6, SIP, SDP, UDP, DHCP, GARP, TFTP, HTTPS, RTP, RTCP, Cisco Discovery Protocol, LLDP
Cables included	USB
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %
USB connector type	USB Type-C
RJ-45 ports quantity	1

Weight and Dimensions

Width	278 mm
Height	61 mm
Weight	1850 g
