Cisco Catalyst 2950 Hardware Installation Guide

3-3
Catalyst 2950 Desktop Switch Hardware Installation Guide
78-11157-05
Chapter 3 Installation
Preparing for Installation
Warning Do not stack the chassis on any other equipment. If the chassis falls, it can
cause severe bodily injury and equipment damage.
Warning To comply with safety regulations, mount switches on a wall with the front
panel facing up.
Warning If a redundant power system (RPS) is not connected to the switch, install an RPS
connector cover on the back of the switch.
Warning The plug-socket combination must be accessible at all times because it serves
as the main disconnecting device.
Warning To prevent the switch from overheating, do not operate it in an area that
exceeds the maximum recommended ambient temperature of 113
° F (45 ° C). To
prevent airflow restriction, allow at least 3 inches (7.6 cm) of clearance around
the ventilation openings.
Warning When installing the unit, always make the ground connection first and
disconnect it last.
Warning This equipment is intended to be grounded. Ensure that the host is connected to
earth ground during normal use.
Warning Before working on equipment that is connected to power lines, remove jewelry
(including rings, necklaces, and watches). Metal objects will heat up when
connected to power and ground and can cause serious burns or weld the metal
object to the terminals.

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
