Chapter 3 Installation
Installing the Switch on a Wall
Installing the Switch on a Wall
Warning To comply with safety regulations, mount switches on a wall with the front
panel facing up.
Warning If a redundant power system (RPS) is not connected to the switch, install an RPS
connector cover on the back of the switch.
You can mount the Catalyst 2950 switch to a wall in a face-up configuration. To
attach the switch to a wall, follow the procedures in this section.
1. Attaching the Brackets to the Switch, page 3-23
2. Attaching the RPS Connector Cover, page 3-24
3. Mounting the Switch to a Wall, page 3-25
Attaching the Brackets to the Switch
Use the supplied Phillips flat-head screws to attach a bracket to the switch.
Figure 3-18 shows how to attach the bracket to one side of the switch. Follow the
same steps to attach the second bracket to the opposite side of the switch.

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
